It’s easy to install the Nest Thermostat. Everything you need comes in the box. And it’s quick – most people install it in 30 minutes or less. Need help? You can call us 24/7.
The Nest Thermostat works in most homes. It figures out what system you have and turns on the right features for you.
Add to Wishlist
Add to Wishlist
Description
| Generation | 3rd Generation |
| Color | Stainless Steel White Black Copper Polished Steel Brass Mirror Black |
| Screen | 24-bit color LCD 480 x 480 resolution at 229 pixels per inch (PPI) 2.08 in (5.3 cm) diameter |
| Languages | English (US, UK) Dutch French (Canada, France) Italian Spanish (Americas, Spain) |
| Compatibility | The Nest Learning Thermostat works with 95% of 24V heating and cooling systems, including gas, electric, forced air, heat pump, radiant, oil, hot water, solar and geothermal. Heating: 1,2, and 3 stages (W1, W2, W3) Cooling: 1 and 2 stages (Y1, Y2) Heat pump: with auxiliary and emergency heat (O/B, AUX, E) Humidifier or dehumidifier (HUM, DEHUM) Fan (G) Power (C, RH, RC) |
| Sensors | Temperature Humidity Near-field activity Far-field activity Ambient light |
| Wireless | Wi-Fi 802.11b/g/n @ 2.4GHz, 5GHz 802.15.4 @ 2.4GHz Bluetooth Low Energy (BLE) |
| Size and weight | Display Mass: 7.25 oz (205.4 g) Diameter: 3.3 in (8.4 cm) Height: 1.06 in (2.69 cm)Base Mass: 1.35 oz (38.3 g) Diameter: 3 in (7.6 cm) Height: 0.42 in (1.1 cm)Assembled Mass: 8.6 oz (243.7 g) Diameter: 3.3 in (8.4 cm) Height: 1.21 in (3.08 cm) |
| Battery | Built-in rechargeable lithium-ion battery |
| Power consumption | Less than 1 kWh/month |
| Remote control requirements | Wi-Fi connection with internet access Nest app on phone or tablet with Android or iOS. See the Nest app requirements for supported versions. Latest version of Safari, Chrome, Firefox or Internet Explorer on Mac OS X v10.9 or later and Windows 7 or later |
| Certification | ENERGY STAR |
|
Multi-home support
|
Multi-zone homes You can control up to 20 thermostats per home. |
| Nest in three homes You can control Nest Thermostats in three locations from one Nest account. | |
| Green | RoHS compliant REACH compliant Recyclable packaging Title 20 battery charger compliant Learn more at nest.com/responsibility |
| Warranty | 2-year limited warranty. For support, visit nest.com/support Our support team is also available by phone 24/7. |
| In the box | Display Base Optional trim kit Mounting screws and labels Nest screwdriver Installation Guide Welcome Guide Nest Pro installation card |
